| Factor forma |
4U |
| M/B Formato |
ATX (12” x 13”) |
| Dimensiones |
546 x 430 x 176 (mm), 21.5” x 16.9” x 6.9” |
| Bahías Unidades |
External 3.5": 1 ;External 5.25": 3 ;Internal 3.5": 4 ;Slim ODD: 1 |
| Formato PSU |
PS/2 Single or Mini-redundant |
| Indicadores |
1 x Power Status, 1 x HDD Activity, 2 x LAN Activity |
| Botones Frontales |
Power On/Off, System Reset, 2 x USB 2.0/USB 3.0(option), alarm mute |
| Sistema Seguridad |
Intrusion Switch, Key lock on front door |
| Ventiladores Refrigeración |
Front: 1 x 120mm (T=25mm), PWM, Rear: 2 x 80mm (Option) |
| Ranuras expansión |
7,8 (RM41300G) or 15 x Full Height and Full Length |
| HDD backplane |
N/A |
| Espesor metal |
1.2 mm |
| Peso neto |
12.5 kg |
| Peso bruto |
15.5 kg |
